10200

Technical information		10200
Maximum reach	m	10,2
Work pressure	bar	180 / 220
Lifting force (gross)	kNm	89 / 109
Slewing torque (gross)	kNm	23 / 28
Optimal oil flow (FIX system)	l/min	60 - 70
Optimal oil flow (LS system)	l/min	90
Flange rotator	kNm	55
Suitable trailers		342 / 346
Suitable grapples		G22E / G24 / G25E / G27
